SANT CS-11 Cast Steel Ball Valve – Flanged, Class 150 (IBR Approved) The SANT CS-11 Cast Steel Ball Valve is a high-performance three-piece, lever-operated ball valve designed for industrial flow isolation. It features a cast carbon steel ASTM A216 Gr. WCB body, stainless-steel ball and stem, renewable PTFE/RPTFE seating, and ANSI B16.5 Class 150 raised-face flanged ends. SANT specifies the CS-11 for water, oil, gas and steam applications. The valve is manufactured to BS 5351 / API 6D, with Class 150 pressure rating and a maximum working temperature of 250°C. It is also listed by SANT as IBR Approved, with an IBR Form III-C test certificate furnished with every supply. SANT CS-11 Cast Steel Ball Valve Specifications Specification Details Brand SANT Model CS-11 Product Cast Steel Ball Valve Standard BS 5351 / API 6D Pressure Class Class 150 Pattern Straight Type Design Three Piece Operation Lever Operated Body Material Cast Carbon Steel ASTM A216 Gr. WCB Ball Material SS ASTM A351 Gr. CF8 / AISI-304 Stem Material SS ASTM A276 Type 410 Seat Renewable PTFE / RPTFE Gland Packing PTFE End Connection Flanged Flange Standard ANSI B16.5 Class 150 R.F. Body Test 30 bar g / 435 psig Hydraulic Seat Test 22 bar g / 320 psig Hydraulic Air Seat Test 6.9 bar g / 100 psig Maximum Working Temperature 250°C HSN Code 84818030 Certification IBR Approved IBR Certificate Form III-C furnished with supply Specifications are based on SANT's current CS-11 product documentation. Available Sizes SANT CS-11 is available in: 25 mm / 1 inch 40 mm / 1½ inch 50 mm / 2 inch 65 mm / 2½ inch 80 mm / 3 inch 100 mm / 4 inch SANT notes that actual dimensions may change as part of ongoing design improvements, so dimensions should be confirmed before ordering. Key Features of SANT CS-11 Class 150 cast steel ball valve IBR Approved Three-piece construction Lever-operated quarter-turn design ASTM A216 Gr. WCB cast steel body SS CF8 / AISI-304 ball AISI-410 stainless-steel stem Renewable PTFE/RPTFE seat ANSI B16.5 Class 150 raised-face flanged ends Suitable for high-reliability industrial flow isolation Maximum working temperature up to 250°C IBR Form III-C test certificate supplied with every supply according to SANT documentation. Applications The SANT CS-11 Cast Steel Ball Valve is suitable for: Steam lines Oil pipelines Gas lines Water pipelines Industrial process piping Power plant applications Boiler and steam-system applications General industrial flow isolation SANT officially lists Water, Oil, Gas and Steam as applications for CS-11. SANT CS-11 Ball Valve Dealer & Supplier in Delhi NCR NAMOKAR ENTERPRISES supplies industrial valves and SANT valve products for customers in Delhi NCR and across India. If you are looking for a SANT CS-11 Cast Steel Ball Valve Class 150, Flanged, IBR Approved, NAMOKAR ENTERPRISES can assist with product availability, required valve size, technical specifications and quotation. Why Choose NAMOKAR ENTERPRISES? SANT industrial valve range Industrial valve supplier in Delhi NCR Cast steel ball valve supply IBR valve requirements Multiple valve sizes B2B and industrial requirements Bulk and project enquiries Supply support across India Frequently Asked Questions 1. What is SANT CS-11? SANT CS-11 is a Cast Steel Ball Valve, Flanged, Class 150 and IBR Approved. 2. Is SANT CS-11 IBR approved? Yes. SANT identifies the CS-11 as IBR Approved and states that an IBR Form III-C test certificate is furnished with every supply. 3. What is the body material? The body is made from cast carbon steel ASTM A216 Gr. WCB. 4. What is the pressure class? The CS-11 is rated Class 150. 5. What type of end connection is used? The valve has ANSI B16.5 Class 150 R.F. flanged ends. 6. What is the maximum working temperature? The specified maximum working temperature is 250°C. 7. What materials are used for the ball and stem? The ball is SS CF8 / AISI-304, while the stem is AISI-410 stainless steel. 8. What industries use CS-11? It can be used in water, oil, gas and steam services, including industrial and power-related piping applications. 9. What sizes are available? The listed range is 1 inch to 4 inches: 25, 40, 50, 65, 80 and 100 mm. 10. Where can I buy SANT CS-11 in Delhi? You can contact NAMOKAR ENTERPRISES for SANT CS-11 availability, specifications and quotation.

SANT CI-17 Cast Iron Ball Valve – Class 125, Screwed (ISI Marked) SANT CI-17 Cast Iron Ball Valve is a straight-pattern, two-piece ball valve designed for reliable flow isolation in water, oil and gas applications. It is manufactured with a cast iron body conforming to IS:210 Gr. FG220, stainless-steel ball and stem, and renewable PTFE seats. The valve has female parallel screwed ends as per IS:554 and is available in sizes from 15 mm to 100 mm (½“ to 4“). Product Specifications Specification Details Brand SANT Model CI-17 Product Cast Iron Ball Valve Standard IS:9890 Class 125 Pattern Straight Design Two Piece Body Material Cast Iron IS:210 Gr. FG220 Ball SS AISI-304 Stem / Spindle SS AISI-410 Seat Renewable PTFE / Teflon Gland Packing Teflon Rings End Connection Screwed Female Parallel Thread Standard IS:554 Body Test Pressure 300 Psig Hydraulic Seat Test Pressure 220 Psig Hydraulic / 100 Psig Air HSN Code 84818030 Marking ISI Marked These specifications are based on SANT Valves' official CI-17 product information. Available Sizes 15 mm / ½“ 20 mm / ¾“ 25 mm / 1“ 32 mm / 1¼“ 40 mm / 1½“ 50 mm / 2“ 65 mm / 2½“ 80 mm / 3“ 100 mm / 4“ SANT lists the CI-17 in all of these nominal sizes. Key Features Class 125 cast iron ball valve ISI Marked product Two-piece straight-pattern construction Cast iron IS:210 Gr. FG220 body Stainless-steel AISI-304 ball Stainless-steel AISI-410 stem Renewable PTFE/Teflon seats Female parallel screwed ends as per IS:554 Quarter-turn lever operation Suitable for water, oil and gas service Works test certificate supplied with every supply by SANT, according to its product documentation. Applications The SANT CI-17 Cast Iron Ball Valve can be used for: Water supply and distribution Industrial piping systems Oil handling systems Gas service applications Utility pipelines Plumbing and process lines General industrial flow isolation SANT specifically lists water, oil and gas as applications for this model. SANT CI-17 Ball Valve Dealer & Supplier in Delhi NCR NAMOKAR ENTERPRISES supplies SANT Valves in Delhi and serves customers across Delhi NCR and India. The company currently lists SANT Valves among its product categories and promotes itself as a SANT valves dealer/supplier in Delhi. For SANT CI-17 Cast Iron Ball Valve Class 125, Screwed, customers can contact NAMOKAR ENTERPRISES for product availability, size requirements, technical specifications and quotation. Why Choose NAMOKAR ENTERPRISES? SANT valve product range Industrial valve supply in Delhi Multiple valve sizes and configurations B2B supply for industrial and commercial requirements Support for bulk and project requirements Delivery support across Delhi NCR and other Indian locations NAMOKAR ENTERPRISES 📞 08048047905 📧 sales@namokarenterprises.com 📍 Delhi, India 🌐 www.namokarvalves.com FAQs 1. What is SANT CI-17? SANT CI-17 is a Cast Iron Ball Valve, Class 125, Screwed and ISI Marked. 2. What is the body material of CI-17? The body is Cast Iron IS:210 Gr. FG220. 3. What type of connection does CI-17 have? It has female parallel screwed threads according to IS:554. 4. What is the pressure class of SANT CI-17? The product standard is IS:9890 Class 125. 5. What material is used for the ball? The ball is stainless steel AISI-304. 6. What material is used for the stem? The stem is stainless steel AISI-410. 7. What type of seat is provided? The valve uses a renewable PTFE/Teflon seat. 8. What sizes are available? The official range is 15 mm to 100 mm (½“ to 4“). 9. Where is CI-17 used? SANT lists it for water, oil and gas applications. 10. Where can I buy SANT CI-17 in Delhi? You can contact NAMOKAR ENTERPRISES, Delhi for availability and quotation.

SANT CI-18 Cast Iron Ball Valve – Class 125, Flanged (ISI Marked) SANT CI-18 Cast Iron Ball Valve is a three-piece, hand-lever-operated flanged ball valve designed for flow isolation in water, oil and gas applications. SANT specifies the valve to IS:9890 Class 125, with a Cast Iron IS:210 Grade FG220 body, SS AISI-304 ball, SS AISI-410 stem and renewable Teflon seat. It is ISI marked and supplied with a works' test certificate. Product Specifications Specification Details Brand SANT Valves Model CI-18 Product Cast Iron Ball Valve Class Class 125 Standard IS:9890 Class 125 ISI Status ISI Marked Design Three-Piece Operation Hand Lever Body Material Cast Iron IS:210 Grade FG220 Ball Material Stainless Steel AISI-304 Stem Material Stainless Steel AISI-410 Seat Renewable Teflon Gland Packing Teflon Rings End Connection Flanged Flange Standard IS:3516-1966 undrilled / B.S.10 Table F Body Test Pressure 300 Psig / 21 bar(g), Hydraulic Seat Test Pressure 220 Psig / 15.4 bar(g), Hydraulic Seat Air Test 100 Psig / 6.9 bar(g) HSN 84818030 Applications Listed by SANT Water, Oil, Gas The above specifications are based on SANT Valves' official CI-18 product page and catalogue. Available Sizes SANT's current CI-18 specification lists sizes from 15 mm to 100 mm (1/2“ to 4“). Size Inch 15 mm 1/2“ 20 mm 3/4“ 25 mm 1“ 32 mm 1-1/4“ 40 mm 1-1/2“ 50 mm 2“ 65 mm 2-1/2“ 80 mm 3“ 100 mm 4“ Key Features of SANT CI-18 Cast Iron IS:210 Grade FG220 body Three-piece construction Class 125 design ISI marked Hand-lever operation SS AISI-304 ball SS AISI-410 stem Renewable Teflon seat Teflon ring gland packing Flanged connection Designed according to IS:9890 Class 125 Works' test certificate supplied with every valve Applications SANT officially lists water, oil and gas as applications for the CI-18. It can therefore be considered for suitable: Water distribution systems Industrial water lines Oil handling systems Utility piping Industrial process lines Pumping systems General fluid isolation Commercial and industrial piping installations Final selection should be based on the actual fluid, pressure, temperature and installation conditions. SANT CI-18 Ball Valve Dealer in Delhi NCR NAMOKAR ENTERPRISES supplies SANT industrial valves for customers across Delhi NCR and Pan India. SANT CI-18 Cast Iron Ball Valve requirements can be sourced for: Delhi Gurgaon / Gurugram Noida Faridabad Ghaziabad Manesar Bhiwadi Sonipat Pan India For bulk orders, industrial projects and regular requirements, customers can enquire for the required CI-18 size and quantity. Why Choose NAMOKAR ENTERPRISES? SANT valve product sourcing Cast iron valve supply Industrial valve supplier Bulk and project requirements Multiple CI-18 sizes Delhi NCR supply support Pan-India supply Application-based valve assistance Frequently Asked Questions 1. What is SANT CI-18? SANT CI-18 is a Cast Iron Ball Valve, Class 125, Flanged and ISI Marked. It has a three-piece construction and hand-lever operation. 2. What is the standard of CI-18? The valve is manufactured to IS:9890 Class 125 according to SANT's product specification. 3. What material is used for the CI-18 body? The body is Cast Iron IS:210 Grade FG220. 4. What material is the ball? The ball is stainless steel AISI-304, while the stem is stainless steel AISI-410. 5. What type of seat is used? CI-18 uses a renewable Teflon seat with Teflon ring gland packing. 6. What type of end connection does CI-18 have? It has flanged ends specified as per IS:3516-1966 undrilled / B.S.10 Table F. 7. What is the body test pressure? SANT specifies a 300 Psig (21 bar g) hydraulic body test pressure. The hydraulic seat test is 220 Psig (15.4 bar g), with a 100 Psig (6.9 bar) air test also specified. 8. Is SANT CI-18 ISI marked? Yes. SANT identifies the CI-18 as Class 125, Flanged (ISI Marked). 9. What sizes are available? The official specification lists 15 mm to 100 mm, equivalent to 1/2“ to 4“. 10. Where can I buy SANT CI-18 in Delhi NCR? You can contact NAMOKAR ENTERPRISES for SANT CI-18 Cast Iron Ball Valve requirements in Delhi NCR and for Pan-India supply.
