SANT CS-7B Cast Steel Gate Valve Dealer In Delhi
NAMOKAR ENTERPRISES – Sant Valves Distributor and Channel Partner
Looking for a SANT CS-7B Cast Steel Gate Valve in Delhi NCR? NAMOKAR ENTERPRISES handles enquiries for Sant industrial valves for compatible industrial and commercial piping applications.
The SANT CS-7B is a Class 600 cast steel gate valve with flanged end connections. It features a cast carbon steel body, bolted bonnet, outside screw and yoke (OS&Y) design, rising stem and renewable seat. Its wedge is specified as solid or flexible, with stainless steel AISI 410 trim and aluminium bronze sleeves.
Designed for on/off flow isolation, this valve is intended for compatible piping systems where pressure rating, material selection and reliable shut-off are important. The valve should be selected according to the operating conditions and the manufacturer's specifications.
SANT CS-7B Cast Steel Gate Valve – Technical Specifications
| Specification | Details |
|---|---|
| Brand | SANT |
| Model | CS-7B |
| Product Type | Cast Steel Gate Valve |
| Pressure Class | Class 600 |
| Product Standard | BS 1414 / API 600, as specified |
| Pattern | Straight Type |
| Body Material | Cast Carbon Steel |
| Material Grade | ASTM A216 Grade WCB |
| Bonnet Design | Bolted Bonnet |
| Stem Design | Outside Screw and Yoke (OS&Y), Rising Stem |
| Seat Type | Renewable |
| Wedge Type | Solid / Flexible Wedge |
| Trim | Stainless Steel AISI 410 and Aluminium Bronze Sleeves |
| End Connection | Flanged |
| Flange Standard | ASME B16.5, Class 600, Raised Face (RF), undrilled as specified |
| Body Hydraulic Test Pressure | 153 barg (2,220 psig) |
| Seat Hydraulic Test Pressure | 112 barg (1,630 psig) |
| Seat Air Test Pressure | 6.9 barg (100 psig) |
| Test Documentation | Manufacturer's works test certificate stated to accompany every supply |
| HSN Code | 84818030 |
Confirm valve size, flange drilling, pressure-temperature rating, material configuration and applicable standards before ordering.
What Is a Cast Steel Gate Valve?
A cast steel gate valve is an industrial isolation valve used to start or stop fluid flow through a pipeline. When fully open, its gate moves out of the main flow path, making the valve suitable for on/off service rather than routine throttling.
Cast steel gate valves are selected for industrial piping systems based on the required pressure class, operating temperature, fluid compatibility, connection type and applicable engineering standards.
Key Features and Benefits of the SANT CS-7B
Class 600 pressure class: For compatible service within the manufacturer's pressure-temperature limits.
ASTM A216 WCB body: Cast carbon steel construction as specified in the product information.
Bolted bonnet: Provides access for inspection and maintenance according to manufacturer instructions.
OS&Y rising stem: Allows visual indication of stem movement during operation.
Renewable seat: Supports seat replacement where permitted by the valve design.
Solid or flexible wedge: Gate design specified for this model.
AISI 410 stainless steel trim: Provides the specified trim material.
Flanged connections: Raised-face flanges specified to ASME B16.5, Class 600.
Works test certificate: The supplied product information states that a test certificate accompanies every supply.
Applications of Cast Steel Gate Valves
The SANT CS-7B may be considered for compatible applications such as:
Industrial process piping
Power and utility installations
Oil and gas process systems, subject to service suitability
Industrial water and utility lines
High-pressure pipeline isolation
Industrial equipment requiring on/off flow control
Actual suitability depends on the process fluid, pressure, temperature, corrosion conditions and applicable industry requirements.
SANT CS-7B Gate Valve Supplier in Delhi NCR
NAMOKAR ENTERPRISES is a distributor and channel partner for Sant, Honeywell, Zoloto, L&T Valves, Kranti, Kity and Aira.
We handle industrial valve enquiries across Delhi NCR and nearby markets, including Delhi, Noida, Greater Noida, Ghaziabad, Gurugram, Faridabad, Manesar, Sonipat, Panipat, Hapur, Meerut, Moradabad, Bhiwadi, Bawal and Jaipur.
For a SANT CS-7B Cast Steel Gate Valve enquiry, share the required valve size, quantity, process fluid, operating pressure, temperature and flange requirements. This information helps confirm product availability and configuration.
Frequently Asked Questions
1. What is the SANT CS-7B Cast Steel Gate Valve used for?
The SANT CS-7B is used for on/off flow isolation in compatible industrial piping systems. It is not generally intended for continuous flow throttling.
2. What is the pressure class of the CS-7B gate valve?
The supplied product information specifies Class 600. The permissible working pressure depends on the operating temperature, material and manufacturer's pressure-temperature rating.
3. What material is used for the valve body?
The body is specified as cast carbon steel conforming to ASTM A216 Grade WCB.
4. What type of end connections does the SANT CS-7B have?
The valve has flanged ends specified as per ASME B16.5, Class 600, Raised Face (RF). Confirm the required flange configuration before ordering.
5. What does OS&Y mean in a gate valve?
OS&Y stands for Outside Screw and Yoke. In a rising-stem design, the stem moves visibly as the valve opens or closes.
6. What is the trim material of the CS-7B?
The supplied specifications list stainless steel AISI 410 and aluminium bronze sleeves.
7. What is the body test pressure of the SANT CS-7B?
The supplied product information states a body hydraulic test pressure of 153 barg (2,220 psig).
8. What are the seat test pressures?
The supplied specifications list 112 barg (1,630 psig) for hydraulic seat testing and 6.9 barg (100 psig) for air seat testing.
9. Where can I buy a SANT CS-7B Gate Valve in Delhi NCR?
Contact NAMOKAR ENTERPRISES for product availability, technical details and pricing enquiries for Sant industrial valves in Delhi NCR.
10. How do I select the correct cast steel gate valve?
Check the valve size, pressure class, process fluid, operating temperature, end connection, material compatibility and applicable standards. Confirm the selection with the manufacturer or supplier before purchase.
