The Honeywell V5011N Two-Way Threaded Globe Valve is a robust HVAC control valve designed for accurate modulating and two-position control of water, steam, and glycol solutions. Its red brass body, stainless-steel stem, metal-to-metal seating, and NPT-threaded connections make it suitable for heating and cooling applications in commercial and building HVAC systems.
The V5011N provides 50:1 rangeability, low seat leakage, and accurate positioning when paired with compatible electric or pneumatic actuators.
Two-way threaded globe valve
Available in sizes from 1/2 inch to 2 inches
NPT-threaded pipe connections
Red brass valve body
Stainless-steel stem
Metal-to-metal seats
Low leakage rate of approximately 0.05% Cv
50:1 rangeability according to VDI/VDE 2173
Spring-loaded, self-adjusting packing
Carbon-fiber-reinforced PTFE V-rings
Accurate positioning for temperature control
Equal percentage flow characteristic for water
Linear flow characteristic for steam
Directly coupled electric and pneumatic actuators
Replaceable seats on applicable models
Repack and rebuild kits available for field servicing
Suitable for both modulating and two-position control
Honeywell V5011N Technical Specifications
Specification Details
Product Honeywell V5011N
Valve Type Two-Way Threaded Globe Valve
Pattern 2-Way, Straight-Through
Sizes 1/2' to 2'
Connection Internal NPT Thread
Body Material Red Brass
Body Class ANSI 150 psi
Stem Material Stainless Steel
Seat Stainless Steel, Replaceable*
Packing Spring-loaded Carbon-Fiber-Reinforced PTFE V-Rings
Stroke 3/4 in. (20 mm)
Rangeability 50:1
Leakage Approx. 0.05% Cv
Water Flow Characteristic Equal Percentage
Steam Flow Characteristic Linear
Applications Water, Steam, Glycol Solutions
Control Modulating / Two-Position
*The supplied specifications note an integral brass seat on certain V5011N3xxx 3/4' to 1-1/4' models.
V5011N Model Designations
The Honeywell V5011N family includes different configurations according to the controlled medium and flow characteristic:
Model Family Application Flow Characteristic Action
V5011N1xxx Water Equal Percentage Direct Acting
V5011N2xxx Steam Linear Direct Acting
V5011N3xxx Water Equal Percentage Reverse Acting
Direct acting: stem down to close.
Reverse acting: stem up to close.
Honeywell V5011N Valve Applications
The V5011N is designed primarily for HVAC heating and cooling systems where reliable regulation of water, steam, or glycol is required.
Typical applications include:
HVAC heating systems
HVAC cooling systems
Hot-water systems
Chilled-water systems
Steam control systems
Glycol-water systems
Air handling units
Heating coils
Cooling coils
Commercial building HVAC
Public building HVAC
Temperature control systems
Modulating control systems
Two-position control systems
Building automation systems
The valve can control glycol solutions with concentrations up to 50%, according to the supplied product specification.
Honeywell V5011N Pressure & Temperature Information
Water
The supplied specifications list:
36°F to 248°F: up to 250 psi (17.2 bar)
248°F to 340°F: up to 211 psi (14.5 bar)
Maximum water differential pressure: 230 psid (15.8 bar)
Steam
For the listed configurations:
V5011N2xxx: 100 psi (6.9 bar) at 340°F
V5011N1xxx: 15 psi (1 bar) at 250°F
Actual allowable pressure and temperature should be selected according to the specific valve model and operating conditions.
